aluminum rib boat
Rib boat with twin engines

Liya 20Feet/6.2Meter semi rigid inflatable boat for 12people

loading

Share to:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
sharethis sharing button
Rib boat 620
22ft rigid inflatable boats
rib620 12 passenger rib boat
Recommend HP: 115HP
Max HP: 150HP(If install maximum hp engine,
confirm with factory, very important for boat)
Vacuum absorption for hulls
  • HYP620

  • Liya

  • H.S89031000

Availability:
Quantity:

Liya 20Feet semi rigid inflatable boat for 12people 6.2 meter rib boat hypalon

20Feet Rib boat hypalon

Bow and stern sun cushions, can also replace with the table at bow and stern;

The luxury rib boat 620 can install a luxury swimming plate with stainless steel ladder.

The inside fuel tank can be replace or repairable.

Fiberglass arch with storage place, installing thefoldable canopy

Sun cushions at bow and stern GRP end step at the end of tube

Different Tube and hull colors for choice

•All the fiberglass hullby vacuum absorption with 5 years guarantee, make inside structure more tighter and stronger;
•The PVC core replace traditional plywood inside fiberglass deck, more waterproof,
light weight, stronger.




22Feet Hypalon Boat Tech Specification Data

Full length

620cm/20ft

Full width

245cm/8ft

Inside length

545cm/18ft

Inside width

141cm

Tube diameters

52cm/1.7ft

Engine Shaft

25 inch

Air chamber No

6

Max Person

12

20’ Container

2pcs

Max loading

1345kg

40’ container

4pcs

V shape degree

20°



Category

C


Engine Information

Engine type

Outboard

Fuel type

Gas

Fuel capacity

150L

Recommend HP

115HP

Max HP

(If install maximum hp engine, confirm with factory, very important for boat)

150HP

Engine shaft

25inch

Number of engine

1

Luxury rib boat 620

Standard Accessories


1. Motor mounting plate on transom

2. stainless steel cleats

3. Stern seat with cushions with backrest

4. Hypalon or PVC rubbing strake

5. Seat E, storage box with cushion,table inside

6. Console F-1, with cushion,storage box inside

7. Hypalon or PVC soft handle

8. Bow seat storage box cushion

9. 150 liters fuel tank with oil guage,gas vent and oil filling port, with cable inside deck

10. 2pcs stainless steel D ring at stern ,2pcs at bow

11. UK air valves

12. Iron frame with pulley to place boat

13. 2pcs hydraulic support on console

14. Foot pump & Bilge pump

15. Battery box and switch for 60A

16.Repair kits

17. Drain plug use for deck

18. Drain plug use for inside hull


Hypalon boat 620

Optional Accessories


1. Foldable canopy with stainless steel pole

2. Water ski pole

3. FRP /Stainless arch with storage place, with navigation lights,

3-1. New aluminum arch with navigation lights

4. Water tank, water pump &shower

5. Rigid handles

6. Safety valve to protect tube

(Do not move safety valve, it will work automatically in need)

7. Big or Small anchor base with roller

8. GRP step on end tube

9. Removable sun cushions at the back

10. Teak deck or Computer Numerical Control engraving EVA deck

11. Removable sun cushions in the front

12. Front stainless steel rail
