Open Fiberglass Hull Ribs

Open Rib Tenders 3.3Meter-5Meter/11Feet-16.5Feet


Liya flat deck rib boats also are rigid hull inflatable boats from 2.7 meter to 6.8 meters.

The deck of this rib tender is very open or flat with automatically water discharge simple system. You can use it as flat boat directly, but also can install consoles and seats. All of them are more economy compared with luxury rib boats structure.

This rib boats also called inflatable dinghies, economy inflatable boats, inflatable tenders too.

Tech Specification Data

Model

HYP330 LY380

HYP420

LY430

LY500

Full length

330CM 280CM

420CM

430CM

500CM

Full Width

168CM 168CM

186CM

196CM

196CM

Tube diameter

42cm 42cm

48CM

48CM

48CM

Engine Shaft

15inch 15inch

20inch

20inch

20inch

Air chamber

3 3

4

4

5

Max Person

5 6

6+1

7

8

Max Loading

495kg 655kg

730KG

880KG

899KG

Recommend /Max HP

15/20hp 30.35hp

40/50HP

40/50HP

70/90HP

Hull weight

74kg 94kg

180KG

195KG

250KG

Container QTY

14/28pcs 12/42pcs

6/18pcs

6/14pcs

4/8pcs

Engine Information

Engine type

Outboard

Fuel type

Gas

Recommend HP

40-70HP

Max HP

50-90HP

Engine shaft

20inch

Speed

>20kts

Number of engine

1
